FEATURES

• Mitre scale Features 11 positive stops for amazingly accurate mitre cuts
• Compact and lightweight with lock down motor head effortless transportation
• Extremely light unit weight with rugged construction for maximum jobsite versatility
• Sliding fence for superior material support
• Spindle lock for easy blade changes
• Horizontal D handle design for comfortable and fatigue free operation
• Precision mitre scale designed to provide trouble free adjustment for the life of the saw
• Mitres up to 50 degrees both sides; bevel function up to 48 degrees
• Cam action mitre lock with detent override for superior accuracy
• Wide die cast aluminium base provides plenty of work piece support
• Cutting Capacity at 90ø/90ø : 95 x 89 mm
• Cutting Capacity at 45ø/90ø : 67 x 89 mm
• Cutting Capacity at 90ø/45ø : 95 x 61 mm
• Cutting Capacity at 45ø/90ø : 114 x 25 mm
• Maximum Depth of Cut Saws : 89 mm

SPECIFICATIONS
