FEATURES

• High power abrasion protected motor delivers high overload capabilities for greater durability
• Spindle lock for quick and easy wheel change
• Quick release clamp results in less time in changing the work piece
• Horizontal handle for superior ergonomics and less user fatigue
• Adjustable spark guard allows user to control the direction of the sparks coming from the machine

SPECIFICATIONS

• Weight: 17.5 KG
• Wheel Diameter: 355 MM
• Wheel Bore: 25.4 MM
• No Load Speed: 4000 RPM
• Max.Capacity at  90° [Square profile]: 98X98 MM
• Power Source: CORDED
• Max. Cutting Capacity at 90° [Rectangular Profile]: 115×130 mm
• Max. Cutting Capacity at 90° [L-Shape Profile]: 120×120 mm
• Max. Cutting Capacity at 90° [Rounded Profile]: 125 mm
• Max. Cutting Capacity at 45° [Square Profile]: 98×98 mm
• Max. Cutting Capacity at 45° [Rectangular Profile]: 95×105 mm
• Max. Cutting Capacity at 45° [L-Shape Profile]: 105×105 mm
• Max. Cutting Capacity at 45° [Rounded Profile]: 115 mm
• Sound Pressure: 97.5 dB(A)
• Sound Pressure Uncertainty : 3 dB(A)
• Sound Power : 110.5 dB(A)
• Sound Power Uncertainty: 3 dB(A)
