FEATURES

• 22 kg unit weight and optimized footprint make this the most portable saw in its class
• Steel roll cage protects saw against jobsite drops and impacts
• Rack and pinion fence system; front and rear fence lock and large; clear scales combine to give an extremely accurate and easy to use saw
• Powerful Brushless 54v motor for high performance in all applications
• Fence system provides 610 mm of rip capacity in a portable design for cutting large sheet materials to size
• Cast table top design ensures accuracy and precision

SPECIFICATIONS

• Blade speed: 5800 rpm
• Blade Diameter: 210 mm, Blade Bore: 30 mm
• Bevel Capacity: -3 to 48°
• Max ripping capacity right: 610 mm
• Max ripping capacity left: 318 mm
• Max. Depth of cut at 90 deg: 65 mm
• Max. Depth of cut at 45 deg: 45 mm
• Table size: 485 x 485mm
• Depth: 605 mm, Height: 330 mm, Length: 605 mm
• Sound power: 100 dBA
