KEY FEATURES

• Outstanding cutting performance in both small profiles and large construction timbers up to 110 x 303 mm
• XPS Shadow line cut indicator provides fast accurate alignment of the blade while illuminating the work piece for increased productivity no adjustment required
• Heavy-duty durability with the ability to fully adjust your machine to maintain accuracy over the life of the tool
• New quick release bevel stop setting provides an accurate and simple setting of bevel angles up to 49ø left and right
• Easy to use mitre and bevel controls making the tool fast and simple to change from one set up to another
• Cam action mitre lock function makes mitre setting faster and easier allowing the user to quickly adjust angles between 0° – 50° left and 0° – 60° right
• Long-life Accuracy in Table and Fence Design
• The large dual sliding fence gives maximum support in large material cuts at any angle or combination of angles
• Linear horizontal rails utilize bronze guides to provide maximum precision when cutting materials up to 345 mm wide
• Compact and lightweight design characteristics deliver a saw with enormous capacity which is easy to transport around the jobsite
• Outstanding dust control and deflection away from cutting area
• Electronic speed control for adjusting cutting speed when cutting materials other than wood
• The innovative grooving stop allows the adjustment of the cutting depth for grooving and rebating applications

SPECIFICATIONS

• Power Input: 1675 Watts, Power Output: 960 Watt
• Blade Speed: 1900 – 3800 rpm
• Blade Diameter: 305 mm, Blade Bore: 30 mm
• Bevel Capacity: 49/49°, Mitre Capacity [right/left]: 60/50°
• Cutting Capacity at 90ø/45ø (W x H): 211 x 112 mm
• Cutting Capacity at 90ø/90ø (W x H): 303 x110 mm
• Cutting Capacity at 90ø/90ø (W x H): 345 x 76 mm
• Cutting Capacity at 45ø/90ø (W x H): 268 x 63 mm
• Cutting Capacity at 45ø/90ø (W x H): 345 x 44 mm
• Cutting Capacity at 90ø/45ø (W x H): 244 x 76 mm
• Max. Cutting Capacity at 45ø/45ø: 212 x 76 mm
• Max. Depth of Cut [Saws]: 170 mm
• Weight: 24.8 kg,Length: 770 mm, Height: 396 mm, Depth: 470 mm
• Hand/Arm Vibration – Cutting Wood: <2.5 m/s²
• Uncertainty K 1 (Vibration): 1.5 m/s²
• Sound Power: 100 dB(A), Sound Power Uncertainty: 3 dB(A)
• Sound Pressure: 93 dB(A), Sound Pressure Uncertainty: 3 dB(A)
