KEY FEATURES
- Pressed steel construction for maximum durability
- High power 2.1 kw motor designed for all jobsite applications
- Easy to use bevel and rise and fall mechanisms increase ease of use and accuracy of set up
- 100 mm dust port for dust free use with an extraction system
- Tall fence with rip scale for accuracy
SPECIFICATIONS
- Power Input: 2100 Watts
- Power Output: 1500 Watts
- Blade Speed: 2800 rpm
- Blade Diameter: 315 mm
- Blade Bore: 30 mm
- Bevel Capacity: 45 ø
- Max. Ripping Capacity [right]: 600 mm
- Max. Ripping Capacity [left]: 320 mm
- Max. Depth of Cut at 90§: 94 mm
- Max. Depth of Cut at 45§: 66 mm
- Table Size: 790 x 600 mm
- Weight: 42 kg
- Depth: 610 mm
- Length: 800 (w/o OT) mm
- Height: 985 mm
AED 3096
AED 4128
