KEY FEATURES

• High power; durable motor delivers excellent power even at a maximum depth of cut
• Stable block construction for low vibration running and long service life
• Spindle lock for ease of blade change
• Optimum balance for fatigue-free operation
• Additional handle for two-handed work
• Steel shoe for added durability
• Protection hood for sawdust extraction
• Variable adjustment of the mitre angle to 45ø for added versatility

SPECIFICATIONS

• Power Input: 1750 Watts
• No Load Speed: 4700 rpm
• Blade Diameter: 235 mm
• Blade Bore: 30 mm
• Bevel Capacity: 45°
• Max. Depth of Cut at 90§: 86 mm
• Max. Depth of Cut at 45§: 62 mm
• Weight: 8.2 kg
• Length: 430 mm
• Height: 290 mm
• Hand/Arm Vibration: 2.5 m/s²
• Uncertainty K 1 (Vibration): 1.5 m/s²
• Sound Pressure: 99 dB(A)
• Sound Pressure Uncertainty: 3 dB(A)
• Sound Power: 110 dB(A)
• Sound Power Uncertainty: 3 dB(A)
