KEY FEATURES

• 17% faster drilling in masonry as compared to conventional brushed motors (DCD776)
• LED with delay feature for improved visibility and flashlight functionality
• Brushless Motor giving consistent drilling speeds and reduced maintenance costs with a higher run time
• Rubber over-mold protection for easier handling and installation
• 55% more torque resulting in increased productivity over conventional brushed motors (DCD776)

SPECIFICATIONS

• Battery chemistry: Li-Ion
• Voltage: 18V
• Battery Capacity: 1.5Ah
• Max Torque (Hard):65Nm
• Max Torque (Soft):26Nm
• Power Output: 350W
• No Load Speed (Drilling/Driving):500/1750rpm
• No Load Speed (Hammering):1750rpm
• Beats per Minute: 29750bpm
• Chuck Capacity: 1.5-13mm
• Max. Drilling Capacity [Wood]:50mm
• Max. Drilling Capacity [Metal]:13mm
• Max. Drilling Capacity [Masonry]:13mm
• Weight:1.2kg
• Sound Pressure:85dB(A)
• Sound Pressure Uncertainty:3dB(A)
• Sound Power:96dB(A)
• Sound Power Uncertainty:3dB(A)
• Hand/Arm Vibration – Drilling into metal:<2.5m/s²
• Uncertainty K 1 (Vibration):1.5m/s²
• Hand/Arm Vibration – Hammer drilling into concrete:14m/s²
• Uncertainty K 2 (Vibration):1.5m/s²
• Hand/Arm Vibration – Screw driving without impact :<2.5m/s²
• Uncertainty K 3 (Vibration):1.5m/s²
