FEATURES

• Keyless blade clamp allows quick; hassle free blade change
• Electronic soft start to limit start-up current and kick back reaction
• High power abrasion protected motor delivers high overload capabilities for greater durability
• Keyless mitre adjustments for quick and simple operations
• Cut-off brushes to prevent motor damage at end of brush life
• Horizontal handle for superior ergonomics and less user fatigue
• Large steel base for a large working area and greater stability
• Spindle lock for easy wheel changes
• Keyless vice allows quick material clamping / releasing
• Machined gears for increased durability
• Easy to carry to the jobsite with new integrated carrying handle
• Adjustable spark guard allow the use to adjust the spark direction

SPECIFICATIONS

• Power Input: 2200 Watts
• Power Output: 1350 Watt
• No Load Speed: 4000 rpm
• Wheel Diameter: 355×2.5 mm
• Max. Cutting Capacity at 90ø [Square Profile]: 120×120 mm
• Max. Cutting Capacity at 90ø [Rectangular Profile]: 100×200 mm
• Max. Cutting Capacity at 90ø [L-Shape Profile]: 140×140 mm
• Max. Cutting Capacity at 90ø [Rounded Profile]: 130 mm
• Max. Cutting Capacity at 45ø [Square Profile]: 113×113 mm
• Max. Cutting Capacity at 45ø [Rectangular Profile]: 100×140 mm
• Max. Cutting Capacity at 45ø [L-Shape Profile]: 120×120 mm
• Max. Cutting Capacity at 45ø [Rounded Profile]: 130 mm
• Weight: 18 kg
• Length: 520 mm
• Height: 435 mm
• Sound Pressure: 100 dB(A)
• Sound Pressure Uncertainty: 3 dB(A)
• Sound Power: 112 dB(A)
• Sound Power Uncertainty: 3 dB(A)
