DESCRIPTION

• The fast and precise tool
• Very high speed (no-load speed: 4,000 rpm) for small drilling diameters
• Drill spindle fixed in bearing for high precision
• Compact design and low weight for easier handling when drilling rows of holes

Additional data

• Rated input power: 350 W
• Weight: 1.2 kg
• No-load speed, 1st gear: 0 – 4,000 rpm
• Power output: 136 W
• Rated speed: 3,116 rpm
• Rated torque: 12.3 Nm

Drilling range

• Drilling diameter in wood: 15 mm
• Drilling diameter in aluminium: 8 mm
• Drilling diameter in steel:6.5mm

Total vibration values (Drilling in metal)

• Vibration emission value ah: 6.9 m/s²
• Uncertainty K: 1.5 m/s²

Total vibration values (Screwdriving)

• Vibration emission value ah: 4 m/s²
• Uncertainty K: 1.5 m/s²

Noise/vibration information

• Sound pressure level: 82 dB(A)
• Sound power level: 93 dB(A)
• Uncertainty K: 5 dB

Drilling in metal

• Vibration emission value ah: 6.9 m/s²
• Uncertainty K: 1.5 m/s²

Screwdriving

• Vibration emission value ah: 4 m/s²
• Uncertainty K: 1.5 m/s²
