DESCRIPTION

• Powerful, robust compressor for simple, commercial use
• Oil-lubricated Piston Condenser
• For single phase alternating current
• Operating pressure can be regulated according to application by means of a pressure reducer and manometer
• Convenient pressure switch for good cold starting, complete with relief valve
• Overload protection: protects the motor from overheating
• Rubberized, stable wheels for mobile use
• Additional manometer for displaying the tank pressure
• Rubber-coated handle for comfortable handling

SPECIFICATION

• Suction rate200 l/min / 7.1 cfm
• Filling capacity110 l/min / 3.9 cfm
• Effective delivery volume (at 80% max. pressure)95 l/min / 3.4 cfm
• Maximum pressure8 bar / 116 psi
• Rated input power1.5 kW / 2 HP
• Maximum speed2850 rpm
• Tank capacity50 l / 13.2 gal
• Sound pressure level (LpA)81 dB(A)
• Sound power level (LwA)97 dB(A)
• Dimensions780 x 400 x 625 mm // 30 23/32 x 15 3/4 x 24 5/8 "
• Weight32 kg / 70.5 lbs
• Cable length1.5 m / 5 ft

Noise emission

• Sound pressure level81 dB(A)
• Sound power level (LwA)97 dB(A)
