PRODUCT DESCRIPTION

• Hose connection: SLW 8 mm
• L: 55mm
• L1: 25mm
• D: 27mm
• Weight: 67 gr.
• Max. working pressure: PN 35 bar
• Temperature range: -20°C to +100°C
• Flow rate: 1000 l/min
• Operation: one-handed
• Valve type: one-way shut-off
• Medium: air etc
• Material connecting piece: Brass MS 58
• Material for unlocking sleeve: Brass MS 58
• Valve body material: Brass MS 58
• Valve material: Brass MS 58
• Material spring(s): stainless steel 1.4310
• Material Snap ring(s): stainless steel 1.4310
• Material seal: Perbunan
• Material pin(s): stainless steel 1.4305
• Nominal diameter: 7.2 mm
