FEATURES

• Active vibration control system incorporating a floating rear handle to reduce vibration
• Ideal for drilling large anchor; fixing and through holes in concrete and masonry from 6 to 32 mm in diameter
• Optimized power to weight ratio good power in a lightweight package
• Large hammer mechanism construction guarantees longer tool life and superior performance
• Rotation-stop for light chiselling applications; render and tile removal
• Electronic variable speed switch for total control
• Mechanical clutch increases user control and protection
• Impact-stop for drilling in wood; ceramic; steel and screw driving applications

SPECIFICATIONS

• Tool Holder: SDS-Plus
• Power Input: 1000 Watts
• Power Output: 450 Watt
• Impact energy (EPTA 05/2009): 4.2 J
• No Load Speed: 0-820 rpm
• Blows per Minute: 0-4700 bpm
• Max. Drilling Capacity [Concrete]: 32 mm
• Max. Drilling Capacity [Core bit]: 100 mm
• Max. Drilling Capacity [Wood]: 32 mm
• Max. Drilling Capacity [Metal]: 13 mm
• Weight: 4.2 kg
• Length: 370 mm
• Height: 250 mm
• Width: 85 mm
• Hand/Arm Vibration – Hammer drilling into concrete: 8.2 m/s²
• Uncertainty K 1 (Vibration): 1.5 m/s²
• Hand/Arm Vibration – Chiselling: 7.1 m/s²
• Uncertainty K 2 (Vibration): 1.5 m/s²
• Hand/Arm Vibration – Drilling into metal: <2.5 m/s²
• Uncertainty K 3 (Vibration): 1.5 m/s²
• Hand/Arm Vibration – Screw driving without impact: <2.5 m/s²
• Uncertainty K 4 (Vibration): 1.5 m/s²
• Sound Pressure: 86 dB(A)
• Sound Pressure Uncertainty: 3.0 dB(A)
• Sound Power: 97 dB(A)
• Sound Power Uncertainty 3 dB(A)
