FEATURES

• Active vibration control with floating back handle delivers extremely low vibration and more comfort
• Ideal for drill anchor and fixing holes into concrete and masonry from 4-20mm in diameter
• Optimized power to weight ratio good power in light weight package
• Electronic variable speed switch for total control
• Mechanical clutch increases user control and protection
• The flat piston design results in reducing vibration
• Same power in forward and reverse mode
• Mode collar selector is easy to use and well protected

SPECIFICATIONS

• Tool Holder: SDS-Plus
• Power Input: 650 Watts
• Power Output: 330 Watt
• Impact energy (EPTA 05/2009): 1.9 J
• No Load Speed: 0-2300 rpm
• Blows per Minute: 0?6200 bpm
• Max. Drilling Capacity [Concrete]: 20 mm
• Max. Drilling Capacity [Core bit]: 50 mm
• Max. Drilling Capacity [Wood]: 30 mm
• Max. Drilling Capacity [Metal]: 13 mm
• Weight: 2.6 kg
• Length: 295 mm
• Height: 218 mm
• Width: 75 mm
• Hand/Arm Vibration – Hammer drilling into concrete: 7.9 m/s²
• Uncertainty K 1 (Vibration): 1.5 m/s²
• Hand/Arm Vibration – Drilling into metal: 3.9 m/s²
• Uncertainty K 3 (Vibration): 1.5 m/s²
• Sound Pressure: 87 dB(A)
• Sound Pressure Uncertainty: 3.0 dB(A)
• Sound Power: 98 dB(A)
• Sound Power Uncertainty 3 dB(A)
